Epson FX-2190II Impact Dot Matrix Printer C11CF38201

NOTE:  ****The Epson FX-2190II Impact Dot Matrix Printer is a limited production machine and will only ship direct from Epson.  This may create delays in delivery time. ****

Key Features

• Extreme Reliability: Durable design with very few moving parts; built to withstand dust, humidity, and extreme temperatures
• Low Cost of Ownership: Up to 12 million character ribbon cartridge reduces user intervention and offers low cost per page
• Powerful Productivity: High-speed 9-pin printing at up to 738 characters per second (cps)
• Legacy Compatibility: Supports Epson ESC/P, IBM PPDS, and MICROLINE languages for seamless integration
• Advanced Paper Handling: Accepts cut-sheet paper and multipart continuous forms up to 7 pages thick
• User-Friendly Operation: Intuitive control panel for easy setup and configuration
• Versatile Connectivity: Parallel, USB, optional Serial and Ethernet (IPv6 compatible)
• Eco-Friendly: ENERGY STAR® V2.0 compliant, RoHS compliant, recyclable design

Print Specifications

• Technology: 9-pin serial impact dot matrix
• Print Direction: Bidirectional logic seeking; unidirectional selectable
• ISO Print Speeds:
  • Ultra Speed Draft: 738 cps (12 cpi), 615 cps (10 cpi)
  • High Speed Draft: 612 cps (10 cpi)
  • Draft: 463 cps (10 cpi)
  • Letter Quality: 115 cps (10 cpi)
• Character Sets: 13 tables and 13 international sets
• Fonts:
  • Draft: 10, 12, 15, 17, 20 cpi
  • NLQ: 10, 12, 15, 17, 20 cpi, proportional
• Barcodes Supported: EAN-13, EAN-8, UPC-A, UPC-E, Code 39/128, POSTNET, Codabar, and more

Media and Paper Handling

• Multipart Forms: Up to 1 original + 6 copies with pull tractor (optional); max thickness 0.018″
• Media Width:
  • Single Sheet: 3.9″ to 16.5″
  • Continuous: 4.0″ to 16.0″
  • Cut-Sheet Feeder: 7.2″ to 16.5″
• Media Length:
  • Single Sheet: 3.9″ to 14.3″
  • Continuous: 4.0″ to 22.0″
  • Cut-Sheet Feeder: 10.1″ to 14.0″
• Paper Feed Mechanism: Friction, push/pull tractor (front, rear, bottom), manual insertion, cut-sheet feeder
• Feed Speed: 45 milliseconds per 1/6″; 5.3 inches/second (continuous)

Connectivity & Compatibility

• Standard Interfaces: Bidirectional Parallel (IEEE 1284), USB 2.0
• Optional: Serial Interface Board and Ethernet (10/100Base-TX) with IPv6 (FX-2190II N)
• Input Buffer: 128 KB
• Supported Operating Systems: Windows Vista, XP, 7, 8, 10; Windows Server 2003–2016

Control Panel Functions

• Font and pitch selection
• Pause, tear-off, line feed, form feed
• Load/eject, micro-adjustment
• Panel lockout, reset, menu navigation

Environmental and Physical Specs

• Operating Noise: 55 dBA (ISO 7779)
• Dimensions: 24.1″ W x 14.8″ D x 6.9″ H
• Weight: 20.7 lb
• Power Usage:
  • Operating: ~57 W
  • Ready Mode: ~12 W
  • Sleep Mode: <0.04 W
• Voltage Range: AC 90 – 264 V
• Frequency Range: 49.5 – 60.5 Hz

Reliability & Warranty

• MTBF: 25,000 POH (25% duty cycle)
• MVBF: 52 million lines (excluding printhead)
• Print Head Life: 400 million characters at 14 dots/char
• Ribbon Life: 12 million characters at 14 dots/char

What’s in the Box

• FX-2190II Impact Printer
• AC Adapter
• User’s Manual / Start Here Guide
• Setup Guide
• CD Driver
• Warranty Certificate

Eco Features

• ENERGY STAR® V2.0 certified
• RoHS compliant
• Recyclable product design
• SmartWay® Transport Partner participation

Optional Service Plans

• 1-Year Return for Repair Extended Service Plan
• 2-Year Return for Repair Extended Service Plan
